Innovative Teaching Pedagogies

Home » Mechanical Engineering » Innovative Teaching Pedagogies

Industry Visits
Guest/Expert Sessions
Project/Problem Based LearningsSeminar/Technical Presentations
Flipped ClassroomsOnline Learning Resources SWAYAM/NPTEL. Self Learning Platforms
Use of Demonstrative/concept Models
     Use and Conduction of Virtual Labs    Hands on / Demonstrative Learning
Use of ICT Tools/Infographics

Lab No 1 :
Dynamics of machinery

Equipments :
Rion two channel fft analyzer with accessories, Universal Vibration Tester

Lab No 2 : Metrology &quality control

Equipments :
Gg angle deckor, GG Sodium Monochromatics light unit

Lab No 3 : Turbo machinery

Equipments :
5hp francis turbine test rig, 5 HP Pelton Wheel Turbine Test Rigit

phoca_thumb_m_phoca_thumb_m_refrigeration air conditioning lab

Lab No 4 : Heat transfer

Equipments :
Thermal conductivity of metal rod, Heat transfer in forced convection

Lab No 5 :Thermodynamics

Equipments :
Joule’s paddle wheel apparatus, Reciprocating Air Compressor Test Rig

phoca_thumb_m_phoca_thumb_m_fluid mechanics lab

Lab No 6 : Fluid mechanics

Equipments :
Pipe friction appratus-major losses measurement, Bernoulli’s Theorem Apparatus

Lab No 7 : Engineering graphics

Equipments :
Dissected rectangular prism, pyramid, cone & cube

Lab No. 8 Mechatronics

Lab No 8 : Mechatronics

Equipments :
Calibration of flow meter apparatus, Setup for switches and relays

phoca_thumb_m_phoca_thumb_m_hydraulics pneumatics lab

Lab No 9 : Hydraulics and pneumatics

Equipments :
Automation studio version 6.1, Hydraulic Trainer

Lab No 10 : Theory of machines

Equipments :
Belt drive system, 4-speed gear box

Lab No 11 :Applied thermodynamics

Equipments :
Three Cylinder Petrol Engine Test setup, Single Cylinder Diesel engine test set up

Lab No 12 : Engineering metallurgy

Equipments :
Ultrasonic flaw detector, Brinell Cum Vickers Hardness Tester

Lab No 13 : Basic mechanical engineering

Equipments :
Babcock & wilcox boiler model, Lancashire fire tube boiler model

phoca_thumb_m_phoca_thumb_m_cad cam lab

Lab No 14 : Cad / cam lab

Equipments :
Catia v5 e19 plm discover pack, Ansys 13.0, Master Cam X5

Lab No 15 : Refrigeration & air conditioning

Equipments :
Ice plant test rig, Air Conditioning Test Rig

Lab No 16 :Strengh of materials

Equipments :
Computerised universal testing machine with electronic extensometer & small double shear test attachment, Digital Torsion Testing Machine

phoca_thumb_m_Lathe-war-2018

Lab No 17 : Workshop

Equipments :
CNC Lathe trainer-Model,TIG welding m/c, Universal Milling machine,

Lab No. 18 Skill Development

Lab No 18 : Skill Development

Equipments :
Engine Assembly, Hydraulic Cylinder Assembly, Tailstock Assembly
