Labs
| Sr.No. | Name of the Laboratory | Name of the Important Equipment |
|---|---|---|
| 1 | Workshop (Central Facility) | ⇒ CNC Lathe ⇒ Arc welding Machine ⇒ Milling Machine ⇒ Spot Welding Machine ⇒ Lathe Machine |
| 2 | Digital Manufacturing Lab /Engineering Metallurgy Lab /Solid Mechanics Lab | ⇒ 3-D Printing Machine ⇒ Impact Testing Machine ⇒ Brinell hardness Tester e ⇒ Rockwell Hardness Tester ⇒ Computerized Universal Testing Machine ⇒ Torsion Testing Machin |
| 3 | Thermodynamics Lab /Turbomachinery / Heating Ventilation and Air Conditioning /Hydraulics and pneumatics | ⇒ Separating and Throttling Calorimeter ⇒ Bomb Calorimeter ⇒ Junker’s Gas Calorimeter ⇒ Single Cylinder Diesel Engine ⇒ 3-Cylinder Petrol Engine/ Pelton Turbine ⇒ Francis Turbine ⇒ Centrifugal Pump ⇒ Impact of Jet ⇒Computerized Ice Plant Test Rig ⇒Air Conditioning Test Rig ⇒Vapour Compression Refrigeration Test Rig |
| 4 | Fluid Mechanics Lab | ⇒ Bernoulli’s Apparatus ⇒ Major/Minor Loss ⇒ Reynold’s Apparatus ⇒ Venturimeter & Orificemeter ⇒ Redwood Viscometer |
| 5 | CAD Lab | ⇒ Ansys 2024 R1 + CFD ⇒ MATLAB 2014 ⇒ MasterCAM X7 ⇒ CATIA V5 R20 ⇒ Robo Analyzer |
| 6 | Dynamics Of Machinery Lab / Kinematics of Machinery Lab | ⇒ Shock Absorber Test Rig ⇒ Universal Vibration Tester ⇒ Static And Dynamic Apparatus ⇒ Rion 2 Channel FFT Analyser ⇒ RION Two channel FFT Analyzer with accessories ⇒ DYTRAN Make Impact Hammer ⇒ Shock Absorbar Test Rig (Computerized Graph) ⇒ Critical Speed of Shaft With Single Rotor System. ⇒ Motorised Gyroscope ⇒ Epicyclic Gear Train ⇒ Cam Jump Apparatus” |
| 7 | Measurement Lab / Mechatronics Lab | ⇒Jominy End Quench Test Apparatus/” ⇒ ⇒ Ultrasonic Flow Detector Calibration of Thermocouple ⇒ Load Cell Trainer ⇒ Level Mea ⇒ Impact Testing Machine ⇒ Verification of P PID PD control ⇒ Setup for witches and relays ⇒Data Acquisition System Trainer ⇒ PLC Based Pneumatic Trainer Kit |
| 8 | Heat Transfer Lab | ⇒ Natural convection Apparatus ⇒Forced Convection Apparatus ⇒Emmissivity Measurement ⇒Thermal Conductivity of Powder |
Lab No 1 :
Dynamics of machinery
Equipments :
Rion two channel fft analyzer with accessories, Universal Vibration Tester
Lab No 2 : Metrology &quality control
Equipments :
Gg angle deckor, GG Sodium Monochromatics light unit
Lab No 3 : Turbo machinery
Equipments :
5hp francis turbine test rig, 5 HP Pelton Wheel Turbine Test Rigit
Lab No 4 : Heat transfer
Equipments :
Thermal conductivity of metal rod, Heat transfer in forced convection
Lab No 5 :Thermodynamics
Equipments :
Joule’s paddle wheel apparatus, Reciprocating Air Compressor Test Rig
Lab No 6 : Fluid mechanics
Equipments :
Pipe friction appratus-major losses measurement, Bernoulli’s Theorem Apparatus
Lab No 7 : Engineering graphics
Equipments :
Dissected rectangular prism, pyramid, cone & cube
Lab No 8 : Mechatronics
Equipments :
Calibration of flow meter apparatus, Setup for switches and relays
Lab No 9 : Hydraulics and pneumatics
Equipments :
Automation studio version 6.1, Hydraulic Trainer
Lab No 10 : Theory of machines
Equipments :
Belt drive system, 4-speed gear box
Lab No 11 :Applied thermodynamics
Equipments :
Three Cylinder Petrol Engine Test setup, Single Cylinder Diesel engine test set up
Lab No 12 : Engineering metallurgy
Equipments :
Ultrasonic flaw detector, Brinell Cum Vickers Hardness Tester
Lab No 13 : Basic mechanical engineering
Equipments :
Babcock & wilcox boiler model, Lancashire fire tube boiler model
Lab No 14 : Cad / cam lab
Equipments :
Catia v5 e19 plm discover pack, Ansys 13.0, Master Cam X5
Lab No 15 : Refrigeration & air conditioning
Equipments :
Ice plant test rig, Air Conditioning Test Rig
Lab No 16 :Strengh of materials
Equipments :
Computerised universal testing machine with electronic extensometer & small double shear test attachment, Digital Torsion Testing Machine
Lab No 17 : Workshop
Equipments :
CNC Lathe trainer-Model,TIG welding m/c, Universal Milling machine,
Lab No 18 : Skill Development
Equipments :
Engine Assembly, Hydraulic Cylinder Assembly, Tailstock Assembly
